AVIATOR

    NOBILE

    2 way Bookshelf


    Nobile, a speaker deeply rooted in Chario’s tradition of construction, detailed sound, with very controlled bass. Soft sound and at the same time absolutely not lacking in high frequencies. The 2-way speaker has shocked everyone since its introduction. It brings together all of Chario’s peculiar features in a reasonably sized cabinet. Deepening to the deeper frequencies, amazing dynamic capacity and high sensitivity make Nobile a sure reference. It can also be used as a monitor in recording studios, literally disappearing leaving space for the music message. It adapts easily to non-optimal acoustical environments




    Details are Important


    The pressure that pushes the air inside the reflex duct is extremely high. Consider the analogy of hydraulic lines that push water upward. As the salt loses fluid pressure, the jets lose speed and weaken. Hence the goal must be to retain the optimal pressure within the reflex duct to ensure a consistent strength in the acoustic wave, while avoiding the audible noise past pressure speeds of 130km/h. The tweeter with a soft dome of 38 mm in diameter, without coolant iron in the air gap, and a “waveguide” support, make it at the same time precise but soft, natural but resolute. Above all, it is so chaste that it can withstand high sound pressures and very low crossover frequencies of the crossover filter, for the benefit of a higher tonal cohesion between the two transducers.



    Wood & Technique

    The amplitude of the curves of this loudspeaker as a power expression, combined with the depth of the massive walnut color, make Nobile a perfect blend of elegance and strength.


    Detailed sound and well-controlled bass. Soft and at the same time absolutely present at high frequencies.


    Grant an open, enveloping, mid-high real section, with a velvety pleasing sound, never tiring. Low frequencies deep, round but still.

    Made of wood of Italian origin, solid massive walnut, handmade


    • Technical Data

      Low Frequency Load

      Vented NRS


      Configuration

      2 -way Reversed Vertical Alignment BookShelf


      Drivers

      1 tweeter 38mm T38Waveguide

      1 woofer 165mm Rohacell® – NeFeB motor


      Sensitivity

      90 dBSPL normalized to 1m/2.83Vrms decorrelated L/R

      pink noise / ITU-R BS 1116-1 compliant room


      Low Frequency Cut Off

      50Hz @ -3dB referred to C4 WETS


      Crossover Frequency

      1180Hz (4th Order)


      Rated Impedance

      Modulus 4Ω (minimum 3.4Ω)

      Argument +/-36°

    • Cabinet & Dimension

      Cabinet

      Solid walnut and HDF.


      Size & Weight

      1??? x ??? x??? mm (H x W x D) / 100 Kg

    • Acoustic Environment & Amplification

      Speakers Orientation

      Speakers should be tilted inward facing the listener


      Ear Listening Height

      Preferably on woofer axis


      Listening Distance

      Optimum speaker-listener distance > 2 m


      Listening Layout

      A carpeted floor in front of the speakers is recommended


      Side and Back Walls

      Should be at least 1m away from the speaker front baffle


      Suggested Amplifier

      120W/4Ω Max Average power

    Balanced Behavior

    Environment & Acoustics


    Most listening spaces are also living areas, and require a balance of acoustic friendliness and the interior design preferences. Aviator was designed with this consideration in mind, and engineered to deal with the significant acoustic problems that affect most living spaces. All the models of Aviator line can easily overcome problems connected with an unbalanced acoustic environment with a too high or too low presence of reflecting or absorbing surfaces. The energy coming from the speaker it’s very directional toward the listeners, this accuracy is one of the reasons why the speakers of Aviator line grant a pleasant listening experience, dramatically decreasing any sort of listening fatigue typical in an untreated acoustic environment. The reversed array alignment choose for the line it’s a consequence of our psychoacoustics studies, the distance between the tweeter and the ground it’s pre calculated and allow us to control it perfectly. The high of the tweeter it’s right at the same high of a seated listener improving in this way his perception of high frequencies.
